Operating Conditions:
1. Ambient Temperature: -5Β°C to 40Β°C (Solenoid will not freeze within this range).
2. Ambient Humidity: 45% to 85% RH (Solenoid will not freeze within this range).
3. Storage Temperature: -40Β°C to 75Β°C.
4. Storage Humidity: 0% to 95% RH.
Performance Specifications:
Temperature Rise: Below 65K (Class A).
Service Life: Over 1 million cycles under load.
Test Environment:
1. Ambient Temperature: 23Β±2Β°C.
2. Relative Humidity: 50Β±10%.
3. Atmospheric Pressure: 1013 hPa.
4. Insulation Resistance: Minimum 100 MΞ© between coil and yoke when measured with a 500V DC insulation resistance tester.
5. Dielectric Strength: Coil and yoke must withstand at least 600V AC for 1 minute.
